Vantage Series 2200
>2) Program Continued
Programming for Flow Applications
From the main screen press the MENU key, then the number 02 keys.
Enter Security ID (00000000 from the factory), then press the ENTER
key and then the 02 keys. The Level Units screen will be visible on the
display. If two sensors are being used, the next screen requires the
selection of the sensor for which the programming applies.
Press the numbers on the keypad that corresponds to the engineering
units desired. Use the UP or DOWN button to move the list up or down.
Select the flow engineering unit desired by pressing the number in front of
the selection. Units available are:
01) GPM, gallons/minute 06) CFD, cubic foot/day 11) MS3, cubic meters/second
02) GPD, gallons/day 07) LPS, liters/second 12) M3H, cubic meter/hour
03) MGD, million gallons/day 08) LPM, liters/minute 13) M3D, cubic meter/day
04) CFS, cubic foot/second 09) LPD, liters/day 14) IGM, imperial gallons/minute
05) CFM, cubic foot/minute 10) MLD, million liters/day 15) BPH; barrels/hour
The FLOW DISPLAY FORMAT screen asks how many digits you want to show to the right of the
decimal point. Press the number that corresponds to your selected value:
01) #. 02) #.# 03) #.## 04) #.###
Example: GPM, #., will show a direct flow reading (e.g. 100 GPM)
The next three screens will be the selection for the type and size of primary element:
3-3
Program/Cal.
01)Level/Vol
02)Flow
03)Totalizer
>01) Flumes 01) Parshall 1) 2 inch 4) 9 inch 7) 24 inch 10) 60 inch
2) 3 inch 5) 12 inch 8) 36 inch 11) 72 inch
3) 6 inch 6) 18 inch 9) 48 inch 12) 84 inch
13) 96 inch
02) Manhole 1) 4 inch 3) 8 inch 5) 12 inch
2) 6 inch 4) 10 inch
0
3) Palmer Bowlus 1) 6 inch 4) 12 inch 7) 21 inch
2) 8 inch 5) 15 inch 8) 24 inch
3) 10 inch 6) 18 inch
Plasti-Fab HQ curves are used for the above, if other manufacturer use SPECIAL.
0
4) Trapezoidal 1) Small V60 3) X-Large V60
2) Large V60 4) 3.0 Ft V60
Plasti-Fab HQ curves are used for the above.
0
5) H Flume 1) H 4.5 Ft 4) HS .6 Ft
2) HL 4.5 Ft 5) HS .8 Ft
3) HS .4 Ft 6) HS 1.0 Ft
Plasti-Fab HQ curves are used for the above.
0
6) Lagco 1) 6 inch 4) 12 inch 7) 21 inch
2) 8 inch 5) 15 inch 8) 24 inch
3) 10 inch 6) 18 inch
Level Units
01)Inches
02)Feet
03)Meters
Level Units
01)Inches
02)Feet
03)Meters
