Eaton 5E Series - Front Panel Description; Rear Panel Description

5
3.2 Front panel
1 2 3
3.3 Rear panel
5E700UI-EA / 5E900UI-EA
1
3
1
3
1
3
2
2
2
4
5E1200UI-EA
5E1600UI-EA / 5E2200UI-EA
1
AC Input
3
Breaker
2
AC Output
4
Fan
1. USBcommunicaonport
2. ON/OFFBuon
3. UPS status LED
