Main menu Submenu Functions
Bypass meters Detailed information on UPS or system bypass meters.
Output meters Detailed information on UPS or system output meters.
UPM Power
Battery meters Detailed information on UPS or system battery meters.
Controls System controls Go Online
Go to bypass
Turn off Charger
Load Off
UPS controls Run battery test
Shut down UPS
Module controls Start charger
Run battery test
Shut down module / Start module
UPM 1:
• Charger
• Battery test
• UPM status
UPM 2:
• Charger
• Battery test
• UPM status
EAA controls ESS:
• Enable
• Disable
• Configure
VMMS:
• Enable
• Disable
• Configure
Enable High Alert
Clear status
ABM:
• Enable
• Disable
• Configure
Clear Alarms
Clear Logs
Mimics UPS mimics An overview of the UPS operation, including information
on load, efficiency and consumption. If there is an error,
an error indicator is displayed next to the affected part.
Active events log can be opened by tapping the error
indicator.
UPS module map Module map shows the status of each UPM.
