Alarm Connections
If required, connect the alarm relay contacts to a remote alarm monitoring system. Use wire
size: 0.5 - 2.0mm2, 20 - 14 AWG.
Alarm relay state
Inverter status
Released
Either:
 the inverter has a fault condition
 ac input is off
 dc input is off.
Operated
Normal operation.
