URTD Module Communications
Interface: Plastic optical fiber (preferred)
Electrical (3 wire)
Fiber Optic Cable: Type HFBR-ELS(length) - precut
low-loss with connectors
Type HBFR-EUS(length) - bulk
low-loss without connectors
Type HBFR-RLS(length) -
standard-loss, acceptable for
<10m
Clock
Accuracy: Freerunning ± 1 minute/month
@ 25°C. Automatically
updated by PowerNet host.
RTC operation without power: 30 Days
IPONI Communications
Type: 2 wire, 115.2 kHz carrier
Baud Rate: 1200 ASK or 9600 FSK
Max. distance: 10,000 feet
Protocol: INCOM
Functions: Read/write set points
Read metered values
Read trip/alarms
Read events
Read history
Reset history
Reset functions
Emergency override
Trip
View Starting Profile
Logging
Log Book: 100 Events
Log Event: 20 Trips & Alarms
Log Start: Last 4 starts
Start Profile: Last 4 starts (Communications
port only)
History Records: Motor, trips, alarms & totals
records
Environmental Ratings
Operating Temp: -20° to + 60°C
Storage Temp: -45° to + 85°C
Humidity: 0 to 95% non-condensing
Dimensions (fixed mount case only)
Height: 10.25 in. (26.04 cm)
Width: 6.72 in. (17.0 cm)
Depth: 3.70 in. (9.40 cm)
Weight: 7 lbs. (15.4 kg)
Standards
UL Recognized: File #E154862
UL Standard: 1053, Ground Fault
Protective Device
ANSI: C37.90, C37.90.1,
and C37.90.2
