Eaton MP-3000 User Manual

Effective 10/02
Page 4-23
For more information visit: www.cutler-hammer.eaton.com
Page 4-23
IL17562BH04
Page Line
TOCS XXX
DescriptionComplete Help Message
TOTAL OPERATION COUNT SINCE
RESET
DATE OF RESET
TIME OF RESET
Display
MM/DD/YY
HH:MM:SS
Page
LOG
LOG
BOOK
Line
START
STOP
EMRG OVR
SET CHNG
RESET
Description
Recalls stored motor events as
observed by the relay
This page contains a chronological list
of motor events
First event recorded – this is just an
example, the event could be any of
the following six types: start, stop,
entering in program mode, emergency
override, alarm condition, or trip
condition. The events listed in the
Line column are used to show all of
the different types of events, but a
true LOG BOOK page will have any
number of different events in the order
that they occur. From the LOG BOOK
display, push line up to see the latest
event. Push again for the next most
recent event and so on. From the LOG
BOOK display, push line down to see
the oldest logged event. Push again
to see the next oldest and so on.The
date that the event occurred The time
that the event occurred
The date that the event occurredThe
time that the event occurred
Emergency override can be activated
from the front face plate, from a
programmed discrete input, or over
the communications network
The date that the event occurred
The time that the event occurred
Recorded every time the program
mode is normally exited. This can
occur with the second push of the
“Prog” push button or over the
communication network.
The date that the event occurred
The time that the event occurred
Logged only when a trip or alarm
event was cleared. This can be done
through the front face panel “Reset”
button, by a programmed discrete
input activation, or over the communi-
cation network.
Complete Help Message
LOG OF EVENTS MODE
LOG BOOK OF THE LAST 100 EVENTS
START EVENT – A STOP TO START
TRANSITION WAS MADE
DATE OF EVENT
TIME OF EVENT
STOP EVENT - A TRANSITION TO THE
STOP STATE WAS MADE
DATE OF EVENT
TIME OF EVENT
EMERGENCY OVERRIDE EVENT – AN
EMERGENCY OVERRIDE WAS PER-
FORMED
DATE OF EVENT
TIME OF EVENT
PROGRAM MODE ENTERED – POS-
SIBLE SET POINT CHANGES
DATE OF EVENT
TIME OF EVENT
RESET EVENT – A RESET EVENT
CLEARED A TRIP OR ALARM
DATE OF EVENT
TIME OF EVENT
Display
MM/DD/YY
HH.MM
MM/DD/YY
HH.MM
MM/DD/YY
HH.MM
MM/DD/YY
HH.MM
MM/DD/YY
HH.MM
Table 4.5 Log Mode Display
