Eaton MP-3000 User Manual

Effective 10/02
Page 4-22Page 4-22
For more information visit: www.cutler-hammer.eaton.comIL17562BH04
Page
HIST TRP
Line
JAMA XX
UL A XX
UB A XX
WD A XX
MB A XX
LB A XX
AX A XX
STXA XX
RTDF XX
URTD XX
TRPS
TRT XXXX
DescriptionComplete Help Message
NUMBER OF JAM ALARMS SINCE
LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF UNDERLOAD ALARMS
SINCE LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF PHASE UNBALANCE
ALARMS SINCE LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF WINDING TEMPERATURE
ALARMS SINCE LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF MOTOR BEARING
TEMPERATURE ALARMS SINCE LAST
RESET
DATE OF RESET
TIME OF RESET
NUMBER OF LOAD BEARING TEM-
PERATURE ALARMS SINCE LAST
RESET
DATE OF RESET
TIME OF RESET
NUMBER OF AUXILIARY TEMPERA-
TURE ALARMS SINCE LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF STARTS PER TIME
ALARMS SINCE LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF RTD CHANNEL FAILURE
ALARMS SINCE LAST RESET
DATE OF RESET
TIME OF RESET
NUMBER OF URTD COMMUNICATION
FAILURE ALARMS SINCE LAST RESET
DATE OF RESET
TIME OF RESET
HISTORY OF TRIP EVENTS
TOTAL NUMBER OF TRIPS SINCE
RESET
DATE OF RESET
TIME OF RESET
TOTAL RUN TIME SINCE RESET
DATE OF RESET
TIME OF RESET
Display
JAMA XX
MM/DD/YY
HH:MM:SS
UL A XX
MM/DD/YY
HH:MM:SS
UB A XX
MM/DD/YY
HH:MM:SS
WD A XX
MM/DD/YY
HH:MM:SS
MB A XX
MM/DD/YY
HH:MM:SS
LB A XX
MM/DD/YY
HH:MM
AX A XX
MM/DD/YY
HH:MM:SS
STXA XX
MM/DD/YY
HH:MM:SS
RTDF XX
MM/DD/YY
HH:MM:SS
URTD XX
MM/DD/YY
HH:MM:SS
MM/DD/YY
HH:MM:SS
MM/DD/YY
HH:MM:SS
