Effective 10/02
Page 4-5
For more information visit: www.cutler-hammer.eaton.com
Page 4-5
IL17562BH04
Page Line Complete Help Message Description
OST XXX TIME LEFT ON OLDEST START IN Remaining time allowed on oldest start for
MINUTES starts per time if programmed. If motor
start/time is exceeded, this is time in minutes
before restart is permitted.
ICM XXXX ADDRESS ON THE IMPACC NETWORK Address of device if on INCOM communications
IN HEXADECIMAL network, only visible if on the network.
MONT MTR DI 1 OFF STATE OF DISCRETE INPUT 1 The current state of discrete input 1. ON =
or DI 1 ON 120Vac present, OFF = 120Vac not present.
DI 2 OFF STATE OF DISCRETE INPUT 2 The current state of discrete input 2. ON =
or DI 2 ON 120Vac present, OFF = 120Vac not present.
MONT TIM DATE AND TIME Current date and time with display format as
programmed.
HH.MM XM CURRENT TIME 12-hour format
or or
HH.MM 24-hour format
MM/DD/YY CURRENT DATE Common format
or or
DD/MM/YY European / military format
