Table 13.3 MP-3000 Drawout Relay Parts List
Description Quantity
MP-3000 Drawout Inner Chassis 1
MP-3000 Drawout Outer Case 1
Outer Flange 1
Mounting Hardware – #10-32 nuts & lock washers 6 each
MP-3000 Instruction Book – I.B. 17562 1
13.3.3 Mounting the MP-3000 Drawout Relay
1. Remove the Drawout Inner Chassis from the outer case.
2. Place the outer case flush against the backside of the panel so
that the case studs project through their respective holes. Refer
to Figure 13.3 for panel mounting diagram.
3. The plastic outer flange is seated on the front of the panel and is
attached to the top, center, and bottom studs that protrude
through the panel with the #10-32 hex nuts and lock washers
included with the relay.
NOTE: Use only the supplied narrow-profile nuts. Standard-
width 10-32 hex nuts will interfere with the insertion of
the inner chassis.
4. The relay inner chassis can now be inserted into the case and
checked for seating into the latching mechanism.
13.3.4 Mounting the URTD Module
There are no provisions for mounting the URTD module on the MP-
3000 Drawout Case. The URTD module must be mounted remotely to
the MP-3000 Drawout.
The URTD module has both an electrical and fiber optic communica-
tion interface to the MP-3000 relay. The electrical connections are
made through the terminal blocks. The fiber optic cable is run through
the opening in the back of the outer case and connected directly to
the inner chassis before it is fully inserted—see Section 13.4.1.
13.3.5 Mounting The PONI Communication Module
The MP-3000 Drawout Relay must be ordered with the communica-
tion module as it is integral to the inner chassis construction and wired
through the terminal connectors. The MP-3000 drawout relay is
available with INCOM communications only.
The communication address is set via switches accessible on the
inner chassis.
