Network Shutdown Module V3 – User Manual - 34 003 934 XU / AE Page 35/65
Note: The status of the Normal Secours box is not yet supervised by Network Shutdown Module V3
z 2 UPSs in Hot-Standby:
Single Phase Comet EXRT, EXRT
Note: Specific configuration for 2 UPSs in Hot standby (Sequential redundancy).
z 2 UPSs in serial redundancy:
Single Phase Pulsar, Pulsar M, EX
Pulsar Extreme C
Evolution
z 2 UPSs through Static Transfer Switch:
Single Phase Pulsar, Pulsar M, EX
Comet EXRT
Pulsar Extreme C
STS 16A (without synchro)
Note: The status of the STS Upsilon box is not yet supervised by the Network Shutdown Module V3
z 2 UPSs powering a server with redundant
power supplies:
Single Phase (without
synchro)
Pulsar M, EX
Pulsar Extreme C
Evolution
Pulsar MX, MX
Comet EXRT, EXRT
