7.2.3 Simple associations of the previous configurations
z Servers with single power supply (and Multiple
STS):
Single Phase (without
synchro)
Pulsar Extreme C
Pulsar M, EX
STS 16A (without synchro)
Notes:
z This configuration has also been tested with 3 STSs
z The Network Shutdown Module V3 is NOT compatible with a configuration where UPS1 and UPS2
are replaced by 2 groups of UPSs.
z Servers with triple power supplies:
Single Phase (without
synchro)
Pulsar, Pulsar M, EX
Pulsar MX, MX
If your configuration is not listed, please contact EATON
