Network Shutdown Module V3 – User Manual - 34 003 934 XU / AE Page 37/65
7.2.4 Configurations NOT supported
z This configuration with STS in cascade is NOT
supported by NSM V3
z This configuration with a load derived between the 2
UPSs in serial redundancy is NOT supported by
NSM V3
z This configuration with a mix of “Parallel” and “STS”
is NOT supported by NSM V3
z The following configuration is NOT supported,
because it is NOT symmetrical on both STS inputs
