Instruction Leaet PUB53675
Effective December 2021
PowerXL DM1 and DM1 Pro series VFD
EATON www.eaton.com
Table 4. Connection sizes and torques.
Output rating Size and torque
Input voltage Frame
size
Drive
catalog
number
CT/IH
current
amps
VT/IL
current
amps
Power
wire size
AWG
(mm2)
Power wire
torque
in.-lb (N·m)
Ground
wire size
AWG
(mm2)
Ground
wire
torque
in.-lb (N·m)
Control
wire size
AWG (mm2)
Control
wire torque
in.-lb (N·m)
AI/DI 
RO
380 Vac to 480 Vac
50/60 Hz
3 phase
FR1 DM1-341D5… 1.5 2.2 14 (2.5) 4.4 (0.5) 14 (2.5) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-342D2… 2.2 4.3 14 (2.5) 4.4 (0.5) 14 (2.5) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-344D3… 4.3 5.6 14 (2.5) 4.4 (0.5) 14 (2.5) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-345D6… 5.6 7.6 14 (2.5) 4.4 (0.5) 10 (2.5) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
FR2 DM1-347D6… 7.6 12 12 (4) 10.5 (1.2) 10 (4) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-34012… 12 16 10 (6) 10.5 (1.2) 10 (6) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-34016… 16 23 8 (10) 10.5 (1.2) 10 (10) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
FR3 DM1-34023.. 23 31 8 (10) 10.5 (1.2) 8 (10) 14.2 (1.6) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
FR4 DM1-34 031… 31 38 6 (16) 33 (3.73) 8 (16) 14.2 (1.6) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-34038… 38 46 4 (25) 33 (3.73) 8 (16) 14.2 (1.6) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
525 Vac to 600 Vac
50/60 Hz
3 phase
FR2 DM1-351D7… 1.7 2.7 12 (4) 10.5 (1.2) 10 (4) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-352D7… 2.7 4.5 12 (4) 10.5 (1.2) 10 (4) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-354D5… 4.5 7.5 12 (4) 10.5 (1.2) 10 (4) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-357D5… 7.5 10 12 (4) 10.5 (1.2) 10 (4) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-35010… 10 13.5 12 (4) 10.5 (1.2) 10 (4) 7.1 (0.8) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
FR3 DM1-35013… 13.5 18 8 (10) 10.5 (1.2) 8 (10) 14.2 (1.6) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
FR4 DM1-35018… 18 22 6 (16) 33 (3.73) 8 (16) 14.2 (1.6) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
DM1-35022… 22 27 4 (25) 33 (3.73) 8 (16) 14.2 (1.6) 28-16 (0.5-1.5) 1.73 (0.2) 4.5 (0.5)
Notes:
 Strip the motor and power cables as shown above.
 Both UL
®
and IEC tools may be used.
 Applies to strained wire, solid wire, or ferrule installations.
(Continued).
