Eaton RE Series User Manual

RE SERIES_ RevA 3/5/2022
v
4
Premier Model(Model REV426100PB is shown)
Essential Model(Model REV426100EB is shown)
Component
Quantity
1
Front vented door with lock
1
2
Rear door
2
3
Top cover
1
4
Side panel
2(with lock)
2(without lock)
5
Vertical rails
4
6
Horizontal beam
4
7
Cable management rail
2
8
Door frame
2
9
Leveling feet
4
10
2" heavy duty castor
4
Note:Other models has similar features
Bottom plate option
Not Shown: Mounting hardware, documentation, shipping brackets and other shipping materials.
Component
Quantity
1
Front vented door with lock
1
2
Rear door
2
3
Top cover
1
4
Side panel with lock
4
5
Vertical rails
4
6
Horizontal beam
6
7
Cable management rail
2
8
Door frame
2
9
Leveling feet
4
10
2" heavy duty castor
4
