9 - SCREEN FORMAT
10 - MAIN SCREEN
Current data Programmed data
Pump operation
LED
Inverter voltage
LED
Main display
Manual stop button
Right selection button
Lower button
Raise button
Left selection button
Alarm
LED
H z 4 8 . 9 ( 4 8 . 8 )
A m p 0 8 . 3 ( 0 8 . 9 )
B a r 0 5 . 5 ( 0 5 . 5 )
1 4 : 5 7 M e n u
Current rotation frequency Instant consumption
Current time Current pressure
Nominal consumption Stop frequency
Setpoint pressure Access to the menu
