INSTRUCTION MANUAL REGARDING USE AND MAINTENANCE
INDEX
1. INTRODUCTION page 2
2. MANUFACTURER IDENTIFICATION DATA page 2
3. GUARANTEE AND TECHNICAL ASSISTANCE page 2
4. GENERAL SAFETY WARNINGS page 2
4.1 PREVENTIVE MEASURES TO BE TAKEN BY THE USER page 2
4.2 IMPORTANT PROTECTIONS AND CAUTIONS page 3
4.3 RESIDUAL RISKS FOR SURFACE PUMPS page 3
5. HANDLING AND STORAGE page 3
6. TECHNICAL-PRODUCTION CHARACTERISTICS page 3
6.1 DESCRIPTION page 3
6.2 USE FOR WHICH PUMPS ARE DESIGNED page 3
6.2.1 USE OF DRINKING WATER page 3
6.3 USE FOR WHICH PUMPS ARE NOT DESIGNED page 3
7. SPECIFICATIONS page 4
7.1 PUMP SPECIFICATIONS page 4
7.2 MOTOR SPECIFICATIONS page 4
7.3 PUMP RATING PLATE page 4
7.4 INFORMATION ON AIRBORNE NOISE page 4
8. PREPARING FOR USE page 4
8.1 COUPLING TO THE MOTOR page 5
8.1.1 ASSEMBLING THE MOTOR TO THE PUMP page 5
8.2 GENERAL INSTALLATION PRECAUTIONS page 5
8.2.1 INSTALLATION page 5
8.2.2 POSITIONING THE PRODUCT page 5
8.2.3 FASTENING DOWN page 5
8.2.4 PIPEWORK page 5
8.3 FLANGE LOADING AND TIGHTENING TORQUES page 6
9. ELECTRICAL CONNECTION page 7
10. FILLING THE PUMP page 7
10.1 FILLING PUMP IN SUCTION LIFT ARRANGEMENT page 7
10.2 FILLING PUMP IN A FLOODED INSTALLATION page 7
11. USE AND STARTING page 7
11.1 GENERAL WARNINGS page 7
11.2 STARTING page 7
11.3 RUNNING page 7
11.4 STOPPING page 8
12. MAINTENANCE AND REPAIRS page 8
12.1 REPLACEMENT OF SHAFT SEAL page 8
13. DISPOSAL page 8
14. TROUBLESHOOTING page 8
15. SUPPLIED TECHNICAL DOCUMENTATION page 10
TECHNICAL APPENDIX page 12
TO BE KEPT BY THE USER
1. INTRODUCTION
Observe the instruction contained therein to obtain best results from the
product. If you need further information, get in touch with your nearest au-
thorized dealer.
NO PART OF THESE ILLUSTRATIONS AND/OR TEXT MAY BE REPRO-
DUCED FOR ANY REASON.
The following symbols have been used in the compilation of this instruction
booklet to make the reader aware of what can happen if instructions are not
complied with:
WARNING!
Risk of damaging the pump or system
Risk of causing injury or damaging property
Electrical hazard
2. MANUFACTURER IDENTIFICATION DATA
2.1 MANUFACTURER DATA
EBARA Pumps Europe S.p.A.
Registeredofce:
Via Campo Sportivo, 30 - 38023 Cles (TN), ITALIA
Telefono: 0463/660411 - Telefax: 0463/422782
2.2 See NAMEPLATE chapter 7.3
3. GUARANTEE AND TECHNICAL ASSISTANCE
FAILURE TO OBSERVE THE INSTRUCTIONS GIVEN IN THIS MANUAL AND
WORK DONE ON THE PRODUCT BY ANYONE OTHER THAN OUR SERVICE
CENTRES VOID THE WARRANTY AND RELIEVE THE MANUFACTURER OF
ALL LIABILITY FOR PERSONAL INJURY AND DAMAGE TO THE PRODUCT.
When you receive the product, make sure that the packaging has not been
damaged externally (breaks/large dents); if so, immediately report the
damage to the shipping agent. Remove the product from its packaging and
check it for shipping damage; report any such damage to the retailer within
8 days of delivery. Check that the ratings on the product’s nameplate match
those of your order.
The following parts, being normally subject to wear, have a limited guaran-
tee:
• bearings
• mechanical seals
• grommets
• capacitors
If a fault that is not listed in the “TROUBLESHOOTING” table (chapter 14)
occurs, please contact the nearest authorised retailer.
4. GENERAL SAFETY WARNINGS
Before using the product, you must be sure you can follow the instructions
given in this manual and apply them whenever using or servicing it.
4.1 PREVENTIVE MEASURES TO BE TAKEN BY THE USER
The user must observe all local safety and accident pre-
vention regulations; he must also observe the product’s
specications(see“TECHNICALDATA”).
Always wear protective gloves when handling the pump or
performing maintenance.
When repairing or servicing the product, shut off its power
supply to prevent the risk of accidental startup, which can
result in injury and damage.
The device can be used by children aged above 8 years
and by persons with reduced physical, sensory or mental
abilities, or who lack adequate experience and knowledge
of the product, provided that they are supervised or have
been adequately instructed on its safe use and the rele-
vant risks involved. Children must not play with the device.
Cleaning and maintenance to be carried out by the user
must not be effected by unsupervised children.
Attempting to service, install or handle the product while
its electrical equipment is live can result in serious and
even fatal injury.
When starting up the product, make sure you are wearing
shoes, not standing in water, and that your hands are dry.
Users must not operate or carry out any work on the motor-
driven pump that is not permitted in this manual.
Stop operation in case pump is in failure. Ope-
ration of broken pumps can cause injury or da-
mage property
