To Next PageTo Next PageWhat does 'WARN: PUMP BOX TEMP HIGH' mean on my EBARA EV-S20P?
If your EBARA Water Pump displays 'WARN: PUMP BOX TEMP HIGH', the cooling water flow may be reduced, or the ambient temperature may be high. Increase cooling water flow or confirm the ambient temperature (less than 30?).
Why is the circuit protector activated on my EBARA EV-S20P?
If the circuit protector is activated on your EBARA Water Pump, it could be due to incorrect wiring or a short circuit. Check the wiring first. If that's not the problem, the pump may have a short circuit, requiring replacement or overhaul.
What to do if EBARA EV-S20P shows ALARM: WATER FLOW LOW?
If the EBARA Water Pump displays 'ALARM: WATER FLOW LOW', several issues could be the cause. It might be that the coupler is disconnected, the pressure isn't sufficient, the root valve is closed, the water pipe is clogged, tube fittings are loosened, there's an instrument failure, or the outlet and inlet pipes are reversed. To resolve this: * Connect the coupler if disconnected. * Apply sufficient pressure. * Open the valve if it's closed. * Clean or replace the piping if clogged. * Re-tighten any loose tube fittings. * Replace the instrument if there is an instrument failure. * Connect pipes correctly if they are reversed.
Why is my EBARA EV-S20P making abnormal noises and vibrating excessively?
If your EBARA Water Pump is experiencing abnormal noise and excessive vibration, here are a few possible causes: * The adjustment feet may not be applied, so use them. * Some object might be making contact with the outer cover, so remove it. * The fastening screws of the outer cover may have worked themselves loose, so tighten them. * Parts of the pump may be damaged, requiring you to replace or overhaul the pump.
What does 'WARN:PUMP N2 VALVE ERROR' mean on my EBARA Water Pump?
If your EBARA Water Pump displays 'WARN:PUMP N2 VALVE ERROR', the N2 valve may be open. Close N2 valve, which is located at the side of the pump.
What does 'ALARM : BACK PRESS.HIGH' mean on my EBARA EV-S20P?
If your EBARA Water Pump displays 'ALARM : BACK PRESS.HIGH', the exhaust valve may be closed, there may be accumulation of by-products in pipes, or there may be instruments failure. Check the exhaust pipe or replace the instruments.
What does 'ALARM:STARTFAIL ALARM/WARN EXIST' mean on my EBARA EV-S20P?
If your EBARA Water Pump displays 'ALARM:STARTFAIL ALARM/WARN EXIST', it could be due to starting during WARNING/ALARM status or instrument failure. Make sure that all starting conditions are met or replace the instrument.
What to do if my EBARA EV-S20P shows 'ALARM: WATER LEAKAGE'?
If your EBARA Water Pump displays 'ALARM: WATER LEAKAGE', it could be due to loosened tube fittings or instrument failure. Re-tighten the tube fittings or replace the instrument.
What to do if my EBARA EV-S20P Water Pump MP does not start when entering external “MP start” signal input?
If the MP on your EBARA Water Pump doesn't start when entering external “MP start” signal input, it might be because “Local” or “COM” mode has been selected, start-up conditions are not satisfied, or there is an instrument failure. Set the switch to “Remote” or satisfy all start-up conditions. If the problem persists, replace the instruments.
What does 'ALARM:BP MOTOR TEMP H.HIGH ALARM:MP MOTOR TEMP H.HIGH' mean on my EBARA EV-S20P?
If the EBARA Water Pump displays 'ALARM:BP MOTOR TEMP H.HIGH ALARM:MP MOTOR TEMP H.HIGH', the cooling water flow may be reduced, or there may be a motor failure. Cool the pump thoroughly and reset it, or replace or overhaul the pump.
Identifies the product as a multi-stage dry vacuum pump.
Warning about lifting operations and qualified personnel.
Instructions on installing CB and interrupting CP before work.
Use N2 gas for diluting flammable/toxic gases and purging piping.
Warning against using the pump for a different process without prior overhaul.
Check for leaks after installing/maintaining piping to avoid hazardous discharge.
Warning against performing withstand voltage tests to avoid damage.
Warning against unauthorized modifications to pump parts or members.
Specific instructions on using M6x12 and M6x16 bolts for lifting brackets.
Caution about hot surfaces and contact with humans/flammable substances.
Safety caution against operating the pump without its cover.
Periodically check safety interlocks to ensure correct operation.
Ebara does not assume risks from mixing gases; users must pay attention.
Warning about hot surfaces that can cause burns.
Warning about hazardous materials that can cause fire, explosion, or poisoning.
Warning about hazardous voltage that can cause shock, burn, or death.
Warning about heavy objects causing injury from falling or tipping.
Reiteration to check safety interlocks every 6 months.
Lists conditions that void the warranty or are not covered.
Procedures for safely shutting off electrical power for maintenance.
Instructions for moving and securing the pump.
Instructions for connecting vacuum and exhaust pipes, including cautions.
Instructions for connecting cooling water pipes and water quality specifications.
Instructions for connecting N2 gas tubing and fittings.
Caution to turn off power and lockout before wiring.
Diagrams showing power supply and control signal connector positions for EV-S20 and EV-S50.
Diagrams showing power supply and control signal connector positions for EV-S100/200.
Tables and diagrams for power supply receptacle pin assignments and specifications.
Emphasizes that electrical wiring must be done by qualified electricians.
Warning to connect the grounding wire properly.
Details the function and system flow of the optional EMS switch box.
How to start and stop the pump using one or two LCD controllers.
Steps to take before starting the pump, including checking water and N2 supply.
Warnings about high temperatures of pump and piping during/after operation.
How to start and stop the pump using the controller's START/STOP buttons.
How to start and stop the pump via communication interface.
How to start and stop the pump using external signals.
Maintenance on vacuum and exhaust piping and safety precautions.
Importance of checking for gas leaks after maintenance.
Precautions for handling toxic gases during disconnection.
Safety measures for disassembly and cleaning.
Safety warnings to be observed before starting maintenance.
Table of basic troubleshooting steps for common abnormal symptoms.
Table of troubleshooting steps for WARNING messages displayed on the LCD.
Table of troubleshooting steps for ALARM messages displayed on the LCD.
Table of troubleshooting steps for optional features and alarms.
General| Model | EV-S20P |
|---|---|
| Category | Water Pump |
| Manufacturer | EBARA |
| Frequency | 50 Hz |
| Impeller Material | Stainless Steel |
| Outlet Diameter | 50 mm |
