SD Series Dry Cabinets Setup and Operation Manual | A55-7379-00 Rev: 2.0.0 Page 16
5.5 SHELF PLACEMENT
Cabinet Shelves are held in place on each side by a shelf support that slips into pre-cut slots. The shelf sup-
ports are symmetrical and can be used to support either the left or right side of the shelf. Slots are pre-cut to
prevent blocking of air vents and LED lighting in addition to fitting most common parts bins, boxes and reels;
place as needed to meet your needs.
To install:
1) Open an cabinet door.
2) Insert the shelf supports into the desired location of the shelf tracks making sure they are both on the
same track notch and secure.
