CONTENTS PAS-225
16 X7732274303
© 01/2020 ECHO Incorporated
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
ASSEMBLY
Power Head Shaft to Lower Shaft Assembly
Do not perform maintenance or assembly procedures with
engine running.
1. Set Power Head/Shaft Assembly on a level surface.
2. Pull locater pin (A) out, and turn counterclockwise one-quarter turn to
lock-out position.
3. Remove vinyl cap from attachment drive shaft.
1 Power Head with Upper Drive Shaft Assembly
1 Operator's Manual
1 Warranty Statement
1 Trimmer Attachment
1 Power Blower Attachment
1 Storage Hook Assembly
1 Support Handle
1 Lower Bracket, Support Handle
2 5 x 30 mm Screws (handle mount)
1 Nylon Trimmer Head
1 Shield with cutoff knife
1 Shield Plate
3 5 x 16 mm Screws (shield mount)
Parts Required: PAS or SRM-SB Power Head Shaft and Coupling
