SPECIFICATIONS PAS-225
48 X7732274303
© 01/2020 ECHO Incorporated
SPECIFICATIONS
MODEL PAS-225
Length 1010 mm (39.7 in.)
Width 246 mm (9.7 in.)
Height 235 mm (9.2 in.)
Weight (dry) 3.75 kg (8.2 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.27 in.)
Stroke 26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust
Spark arrestor muffler or spark arrestor muffler with
catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm [0.026 in.])
Fuel Mixed (Gasoline and Two-stroke Oil)
Gasoline/Oil Ratio 50:1
Gasoline
Use 89 Octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E-15 or
E-85.
Oil
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD
,
two-stroke, air-cooled engine oil.
Fuel Tank Capacity 0.44 l (14.9 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft 6.35 mm (0.25 in.) flexible shaft
Handles Front - Support, Rear Handle (with rubber)
Shoulder Harness Optional
Idle Speed 3,000 RPM
Clutch Engagement Speed 3,850 RPM
Wide Open Throttle Speed
(W.O.T.)
10,000 RPM
MODEL 99944200490 (Power Blower Attachment)
Length 635 mm (25.01 in.)
Width 231 mm (9.10 in.)
Height 212 mm (8.35 in.)
Weight (dry) 1.76 kg (3.89 lbs.)
Drive Shaft 6.35 mm (0.25 in.) Steel shaft
Maximum Air Speed 160 kph (100 mph)
