PAS-225 MAINTENANCE
X7732274303 35
© 01/2020 ECHO Incorporated
Removal of cooling passage blockages or cleaning of cooling fins is
considered “Normal Maintenance.” Any failure attributed to lack of
maintenance is not warranted.
1. Remove spark plug lead.
2. Close choke (COLD START
[ ] position). This prevents
dirt from entering the
carburetor throat when the air
filter is removed. Remove air
cleaner cover (A).
3. Remove engine cover (B).
DO NOT use a metal scraper to remove dirt from the cylinder fins.
4. Use a brush to remove dirt
from the cylinder fins.
5. Remove ignition wires from
clip for cleaning.
A
B

Echo PAS-225 Pro Attachment Series Specifications

General

Engine Displacement	21.2 cc
Shaft Length	59 in
Starting System	i-30™ starting system
Attachment Capable	Yes
Engine Type	2-stroke
Shaft Type	Straight
Cutting Swath	17 in
Line Diameter	0.095 in
Fuel Capacity	14.9 fl. oz.
