Echo PB-8010

28
Specifications
Specifications
These specifications are subject to change without notice.
PB-8010
Mass (Dry, with blower pipes): kg 11.2
External dimensions (without blower pipes):
Length mm 362
Width mm 526
Height mm 544
Engine:
Type Air cooled 2-stroke single cylinder gasoline engine
Engine displacement cm
3
79.9
Maximum power kW 4.2
Engine speed at maximum engine power r/min 8000
Recommended engine speed at full load r/min 7800
Recommended engine speed at idling r/min 2500
Carburettor Diaphragm type
Ignition Flywheel magneto - CDI system
Spark plug NGK CMR7H
Starter Recoil starter
Air volume: (ANSI/OPEI B175.2) m
3
/h 1819
Max. air speed: (ANSI/OPEI B175.2) m/s 94.5
Fuel: Regular grade petrol. Minimum 89 Octane unleaded
petrol is recommended. Do not use fuel containing
methyl alcohol or more than 10 % of ethyl alcohol.
Oil Two stroke, air-cooled engine oil. ISO-L-EGD Stand-
ard (ISO/CD 13738), JASO FC,FD grade and ECHO
recommended oil.
Ratio 50 : 1 (2%)
Tank Capacity (full): mL 2560
Fuel consumption:
Fuel consumption at maximum engine power L/h 2.18
Sound pressure level: (EN15503) L
pAeq
dB(A) 107.3
uncertainty K
pA
dB(A) 2.5
Sound power level: (EN15503) L
WARa
dB(A) 114.2
uncertainty K
WA
dB(A) 2.5
Vibration: (EN15503) a
hv,eq
m/s
2
2.1
uncertainty K m/s
2
1.7
