12
SPECIFICATIONS
* The RPM range shown applies for all attachments. Refer to your attachment Operator's Manual "Specifications"
section for proper RPM specifications.
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time of publication,
but are subject to change without notice. Illustrations may include optional equipment and accessories, and may not
include all standard equipment.
MODEL PAS-2601
Shaft Length
756 mm (29.8 in.)
Unit Width
1015 mm (40.0 in.)
Width
222 mm (8.75 in.)
Height
241 mm (9.50 in.)
Weight (dry) w/Cutter Head
3.9kg (8.6 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore
34.0 mm (1.34 in.)
Stroke
28.0 mm (1.10 in.)
Displacement
25.4 cc (1.55 cu. in.)
Exhaust Spark Arrestor Muffler
Carburetor Walbro diaphragm model WYJ w/purge pump
Ignition System CDI (capacitor discharge ignition)
Spark Plug
NGK BPMR-7A (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl alcohol, more than
10% ethyl alcohol or 15% MTBE.
Oil 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity
0.64 lit. (21.6 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft
6.35 mm (1/4 in.) flexible shaft
Idle Speed 2400 - 3000 RPM
Wide Open Throttle Speed (W.O.T.) 9500 - 11000 RPM
