25
DPAS-2100
99922238047
© 12/2022 ECHO Incorporated
Pro Maxi-Cut
Grass / Weed
Blade
Tri-Cut Grass /
Weed Blade
Metal Grass /
Weed Blade
Metal Brush /
Clearing Blades
Support Handle,
with or without
barrier bar
U-handle or support handle with
barrier bar
U-handle*
Shield with cut-off
knife
Shield without cut-off knife.
Harness Harness
Upper plate/at
washer
Upper / Lower blade plates
Hex nut Hex nut
New cotter pin New cotter pin
*ANSI and UL standards require brushcutters be equipped with a barrier bar or
restrictive harness. U-handle ensures a higher safety factor.
SAFETY
Do Not install blades on GT (Curved Shaft) model trimmers.
• Use only ECHO approved parts. Failure to use the correct parts
can cause the blade to y off. Serious injury to the operator and/or
bystanders can occur.
• Arbor diameter of upper blade plate must match arbor diameter of
blades.
• For barrier bar or U-handle, follow instructions supplied with either
blade conversion kit or U-handle kit, and verify blade is secured
properly.
• A new cotter pin is required each time a blade is installed.
• Shoulder harnesses may be used on all trimmers and brushcutters
to reduce operator fatigue. Brushcutters over 7.5 kg (16.5 lbs.) dry
weight (without fuel) and U-handle brushcutters require a double
shoulder harness.
Note: The barrier bar is used to restrict rearward movement of the unit.
The barrier bar is not a handle and should not be gripped when using
or carrying the unit.
Blade Selection:
Not all blades are compatible with all trimmers. Visit www.echousa. com or
www.shindaiwa-usa.com to nd compatible blades.
