DPAS-2100
9992223804736
© 12/2022 ECHO Incorporated
ASSEMBLY
The attachment will operate when the battery is installed, the
power indicator LED is lit, and the power switch and lock-off lever
switch are engaged. Make sure the unit is properly positioned to
preventloss of control and possible serious injury. Keep movable
parts of the attachment off the ground and away from objects that
could become entangled or thrown.
Note: The battery comes partially charged from the factory and needs to be
fully charged before rst use.
1. Make sure power to unit is turned
off.
2. Align ridges (A) on battery with
grooves in power head. Slide
battery into power head.
3. Assure the battery latch (B) snaps
into place and battery is secure
before beginning operation.
Install the Battery
Remove the Battery
1. To remove battery, depress battery latch release (C) slide battery out of
power head.
C
A
Assure battery latch is fully engaged before using unit.
B
