DPAS-2100
9992223804738
© 12/2022 ECHO Incorporated
OPERATION
Applications
Always hold throttle handle with right hand and support handle
with left hand, placing unit on right side of body.
Do not install blades on GT (Curved Shaft) trimmers.
Operating Techniques - Nylon Line Head
Nylon line heads may be used for trimming, scything, edging, and scalping of
grass and light weeds.
Trimming
Feed the spinning line into the material to be cut. Tilt the line head to one side
to direct cutting debris away from you:
• Model SRM/DSRM/PAS/DPAS/SB/TX/C/T (Straight shaft,
counterclockwise line head rotation) - Tilt the cutting head down on the
right side while cutting to direct cutting debris away from operator. Feed
the line gradually into the material you wish to cut, avoiding contact with
fences or other barriers.
• GT models: Tilt cutting head to the left while cutting to direct debris away
from the operator.
Scything
Scything - Swing the cutting head in a level arc, gradually feeding the line into
the material being cut. Move forward with each arc to cut a swath. Width of
cutting swath depends on arc. Use a larger arc for a wider swath, or a smaller
arc for a narrow swath. Keep line head tilted to direct cutting debris forward or
away from you.
Stop the Machine
1. Release the power switch to stop the machine.
• If the LED remains lit, operation is normal.
• If the LED ashes once per second, the battery needs to be charged.
• If the LED ashes four times per second, there is a fault within the product.
Turn power off to unit. Remove battery. Clear debris from around line
head. Install battery. Turn power on to unit. If ashing continues, have your
authorized servicing dealer repair the product.
