DPAS-2100
9992223804744
© 12/2022 ECHO Incorporated
Cleaning battery and battery compartment
MAINTENANCE
Risk of electric shock or re. Do not use conducting materials to
clean battery or battery compartment. Otherwise serious personal
injury may result.
1. Cut one piece of line to
recommended length.
2.0 mm (0.080 in.) diameter 6 m (20 ft.).
2.4 mm (0.095 in.) diameter 6 m (20 ft.).
2. Align arrows (A) on top of knob with
openings in eyelets (B).
Nylon Line Replacement
Wear gloves or personal injury may result:
• Cut-off knife is sharp.
• Gearcase and surrounding area may be hot.
Never use wire or wire-rope that can break off and become a dangerous
“projectile”. Serious injury can occur.
A
B
A
1. Release power switch and allow
trimmer head to stop.
2. Depress battery latch release (A)
and slide battery out of power head.
3. Use compressed air or a soft bristle
brush to remove debris from battery
and battery compartment.
To Next Page
