6. Specifications
1. Tuner & Channel
Input Connector 1 x F type with Loop through
Output Connector 1 x F type 75 Ohm IF signal out
Frequency Range 950MHz to 2150MHz
Input Impedance 75 Ohm
Signal Level -25dBm to -65dBm
IF Frequency 480MHz
IF Bandwidth 36MHz
LNB Power & Polarization Vertical +13.5V~+14.5V
Horizontal +17.5V~+18.5V
22KHz Tone Frequency 22KHz ±2KHz
Amplitude 0.6Vp-p ±0.2Vp-p
Demodulation QPSK
Input Symbol Rate 2~32Msps
FEC Decoder Convolutional Code Rate
1/2, 2/3, 3/4, 5/6 and 7/8 with Constraint
Length K=7
2. MPEG Transport Stream A/V Decoding
Transport Stream MPEG-2 ISO/IEC 13818
Transport Stream Specification
Profile & Level MPEG-2 MP @ ML
Input T/S Data Rate 80Mbit/S Max.
Aspect Ratio 4:3, 16:9 with Pan Vector
Video Resolution 720 x 576 (PAL), 720 x 480 (NTSC)
Audio Decoding MPEG-1 Audio Layer 1,2, Musicam
Audio Mode Stereo, Dual Channel, Joint Stereo, Mono
Sampling Rate 32, 44.1 and 48KHz
3. Memory
Flash Memory 2M bytes
Program DRAM 8M bytes
EEPROM 2K bytes
