EchoStar DSB-700 FTA - Front Panel; Rear Panel; Front & Rear View

Front Panel
Front Panel
3. Front & Rear View
Rear Panel
Rear Panel
4
Note: All the cables used for Input/Output connection for the receiver should be well shielded.
Note: All the cables used for Input/Output connection for the receiver should be well shielded.
ON/Standby
Channel up / down
AC power cord
LNB input
Antenna input
RF output connector
to TV
