Operation
Adjusting the sound quality
You can fine-tune the audio sound in the audio control mode.
IMPORTANT
BASS J MID J TREB J BAL J FAD J
NON-F J NF-P J LPF J LOUD J SVC ...
■ Adjusting the BASS
You can adjust the bass (low sounds).
● To the right:
Emphasizes low sounds.
To the left:
Softens low sounds.
■ Adjusting the MIDDLE
You can adjust the mid-range sounds.
● To the right:
Emphasizes mid range sounds.
To the left:
Softens mid range sounds.
■ Adjusting the TREBLE
You can adjust the treble (high sounds).
● To the right:
Emphasizes high sounds.
To the left:
Softens high sounds.
■ Balancing the Right and Left
Speakers (BALANCE)
You can adjust the balance of right and left
speakers.
● To the right:
Emphasizes right speakers.
To the left:
Emphasizes left speakers.
■ Balancing the Front and Rear
Speakers (FADER)
You can adjust the balance (fading) of front
and rear speakers.
● To the right:
Emphasizes front speakers.
To the left:
Emphasizes rear speakers.
■ Adjusting non-fader level (NON-
FADER LEVEL)
Non-fader level (for connected sub-woofer)
can be adjusted.
● To the right:
Increases the sub-woofer level.
To the left:
Decreases the sub-woofer level.
Switching Audio Control
Modes
● The audio control mode is canceled if you
press no button more than 6 seconds.
● You can check your settings on the PND
screen when it is attached. When
detached, you can check the settings on
the sub-display.
1
The Audio Control mode is switched in
the following sequence each time you
press the [CTRL] button.
2
You can adjust the level in each mode
by rotating the [VOL] knob.
