12
Chapter 3. Using DVR
1. Basic Operation
1-1. Front Panel & IR Remote Controller
The DVR should be correctly installed before proceeding. The location and the shape of the
buttons may vary depending on the DVR model.
Control
Description
USB Port
Two USB ports are located on the front panel. A USB mouse
can be connected USB port dedicated only for mouse as
picture directed.
Camera Buttons (1~0)
Pressing camera buttons and Enter button will cause the
selected camera to display full screen. Buttons are used to
enter passwords.
MENU / EXIT Button
Enters the Setup Menu. User will need to enter the authorized
password to assess Setup. In Playback mode, MENU button
displays the Playback Menu.
DISPLAY Button
Changes the screen display mode in the current screen or
playback screen.
SEQUENCE Button Displays live channels sequentially.
Up, Down, Left, Right
Arrow, ENTER Buttons
These are used to change settings for the product in MENU
mode or used in PTZ control mode. (pan, tilt)
BACKUP Button Copies recorded data to an external storage device.
PLAYBACK Button Changes to the playback mode from the live mode.
PAUSE Button
Under playback mode, the button can be used to pause the
playback screen.
- Display menu to save PTZ preset under PTZ mode.
PLAY Button
Plays the video forward. Press the button repeatedly to
increase play speed up to max 32 times (1, 2, 4, 8, 16, 32
times) faster. Use this button to move right when setting the
menu.
- Focus on far distance under PTZ mode.
R.PLAY Button
Plays the video backward. Press the button repeatedly to
increase play speed up to max 32 times (1, 2, 4, 8, 16, 32
times) faster. Use this button to move right when setting the
menu.
- Zoom Out under PTZ mode.
STEP FORWARD Button
Move forward by one frame under Pause. Use this button to
move up when setting the menu.
- Focus on near distance under PTZ mode.
STEP BACKWARD Button
Move backward by one frame under Pause. Use this button to
move down when setting the menu.
