3. Specification
Model 8 Channel 16 Channel
In 8 BNC 16 BNC
Video
Out 1VGA,& 1 BNC Main, 1 Spot Output
In 4 RCA (Line-In)
Audio
Out 1 RCA (Line-Out)
Sensor In 8 TTL 16 TTL
Alarm Out 2 Relay + 2 TTL
Device
I/O Interface RS232, RS485, USB2.0 x 3, USB1.1 x 1 for Mouse
Speed Real Time
Resolution 720 x 480 (NTSC), 720 x 576 (PAL)
Display
Split Screen 1,4,9,PIP,Digital Zoom 1,4,9,13,16,PIP,Digital Zoom
Compression H.264 Codec
Speed /
Resolution
120fps@CIF(NTSC)
100fps@CIF(PAL)
60fps@Half D1(NTSC)
50fps@Half D1(PAL)
30fps@D1(NTSC)
25fps@D1(PAL)
240fps@CIF(NTSC)
200fps@CIF(PAL)
120fps@Half D1(NTSC)
100fps@Half D1(PAL)
60fps@D1(NTSC)
50fps@D1(PAL)
Picture Quality Very High, High, Standard, Low
Recording
Mode Time-lapse, Event, Time & Event, Emergency (Panic)
Display 1, 4, 9, Digital Zoom 1,4,9,13,16,Digital Zoom
Search Mode Calendar Search, Event Search, Text-In Search, Go to Time
Playback
Playback Mode
Multi Channel Normal & Reverse Play,
RW & FF ( x2, x4, x8, x16, x32), Frame to Frame, Pause
Interface Ethernet (10/100 Base)
Protocol TCP/IP, HTTP, DHCP, ADSL(PPPoE)
Application Live, Playback, Setup, Notification (Callback, E-Mail)
Network
Web Browse Internet Explorer 7 or higher
Storage 3xSATA HDD & 1xSATA ODD (or max. 4 SATA HDD w/o ODD)
Backup CD & DVD-RW, External HDD(USB), External USB Memory
Control
Front Panel Button, USB Mouse,
IR Remote Controller, Joystick Controller
OSD Graphic User Interface (Multilingual)
Approval FCC, CE, KCC
ROHS ROHS Compliance
Power Consumption DC12V, 6.67A (80W)
Operating Temperature 5°C ~ 40°C / 41°F~104°F
Operating Humidity 0%~80% / non-condensing
Dimension 430(W)x92.5(H)x428(D)mm / 16.9(W)x3.64(H)x16.8(D)inch
Weight 5.38Kg / 11.86lb (without HDD)
