Eclipse T500 Actuator, V1, Instruction Manual 902, 12/7/2009

Ratio Burner

Figure 2.2. Ratio Burner

Ŷ Use of this product in the European community

shall only be deployed in a manner that meets the

applicable EC directives and laws.

Ŷ In areas where DIN regulations apply, the

mounting and installation must comply wth DIN/

VDE 0100, 0550 and DIN/VDE 0722.

Burner

Blower

Actuator Controlling

Air Butterfly Valve

Sensing Line

Ratio Regulator

Fuel Flow

Control Valve

Safety Shut-off Valves

Controlled by

Flame Safeguard

CAUTION
