Overview - Dimensions / Panoramica - Dimensioni / Vue d'ensemble - Dimensions / Descripción - Dimensiones / Обзор - Размеры / Überblick - Größe
X
Y
Z
Packaging
GAS TRAIN DIMENSIONS: refer to GT manual
Ø r
RrSr
d..°
Ø a Ø b
Ø c
125
153
M
10
MAX GAS 70-120
Models
A
B
C
D D1 E
F
G
I
L
M
MAX GAS 70 P 335 176 159 102
- 205 94
160 100/120 100/120
M8
MAX GAS 120 P
335
176 159 102
- 205 94 160
100/120
100/120 M8
Model Ø a Ø b Ø c
d°..
MAX GAS 70 P
110 140
170
45°
MAX GAS 120 P
110 140
170
45°
Model
X
Y
Z
Kg
MAX GAS 70 P 390
300
270
8
MAX GAS 120 P 390 300
270
8
Boiler plate drilling
M
I
L
CB
A
E
D-D1
F
G
