Battery replacement
Battery replacement
https://youtu.be/YPf51vVM5us
The operation of the dispensers requires very little power. This is a set of
4 x 1.5 V AA Mignon LR6 brand-name batteries suffices for about two years
(approx. 30,000 dosing cycles)
. As a rule, the batteries last even longer.
NOTICE!
– Never mix new and used batteries.
– Always use batteries of the same type.
–
In the event the dispenser has not been used for a longer time, the
batteries should be removed to prevent potential loss of charge or
leakage.
– Do not use rechargeable batteries, they do not reach the required
voltage even when fully charged.
Inserting batteries
1.
Open dosing dispenser with key (
Ä
Chapter 3 ‘Scope of delivery’ on page 17).
2. Depending on the stand variant, either remove the bottle or detach the suction-side
pump hose from the hose connector. Pass the pump hose next to each pump
housing to access the battery compartment.
Fig. 8: Insert batteries (4 x AA Mignon LR6)
3. Open battery compartment (Pos. 2).
4. Insert 4 new 1.5 V AA Mignon LR6 batteries (Pos. 3), pay attention to the proper
polarity during the process (see labelling on the battery compartment lid).
5. Close the battery compartment cover (pos. 2).
6. Either replace the bottle (500 or 1000 ml) or connect the pump hose to the canister
hose (5 or 20 l variant) via the hose connector.
7. Close dispenser housing.
Service
36MAN048961, Rev. 2-09.2020
