3.0 SPECIFICATIONS
W
H
D
Alligator Allocator Dispenser
3.1 Dimensions (Dispenser)
• Height (H) : 15" (38.1 cm)
• Width (W) : 13" (33 cm)
• Depth (D) : 5" (12.7 cm)
NOTE - The width of the cabinet includes the protruding
inlet and outlet water manifold fittings.
3.2 Access Requirements
For ease of operation the cabinet should be placed such
that the palm buttons are 4 - 5' (1.2 - 1.5 meters) above the
floor.
3.3 Components Supplied
• Alligator Allocator Dispenser
• Positronic IV Pumps and Cabinets (2)
• Viton anti-siphon Valves and Kits (2)
• 55 Gallon Drum Probes (2)
• Positronic IV Pump Mounting Bracket
• Anti-siphon Valve Holder
• Fill Hoses (2)
• Jug Holder
3.4 Components Not Supplied
• 1/4" air Polyflo tubing (P/N 8501-5105)
•
3/8" ID reinforced pump suction and discharge tub-
ing (P/N 8501-5410).
• Use containers
