EcoQuest LaundryPure - Removing the Cover

13
R E M O V I N G T H E C O V E R
Turn off the cold water valve.
1
Unplug the unit by removing the
power cord from the POWER IN
socket on the LaundryPure.
3
Briefly turn washer to the “ON” position.
This will allow the water to drain from the
LaundryPure unit. Turn the washer OFF.
2
Remove the three (3) cover screws
located on the bottom of the unit.
4
5
Remove the three (3) screws along
the top of the LaundryPure.
To remove the cover, pull the top away
from the unit, then lift off the cover.
6
Electrical Shock Hazard.
Disconnect power before attempting
installation or service.
Failure to follow these instructions can
result in death, fire, or electrical shock.
WARNING:
