15
I N S T A L L I N G U V B U L B S
SOCKET
RETAINER GROMMET
Remove the new bulbs from their
packaging. Line the bulb up with the
retainer grommet.
Push the bulb through the grommet while
lining up the prongs with the socket as
you insert.
Once the bulb is inserted, line up the right
end with the clip and secure the bulb by
pressing gently.
2
1
3
4
5
Reinstall the
UV shield.
Secure the UV shield with six (6)
thumbscrews. Hand tighten only.
When installing your new UV bulbs, make sure you do not
touch the glass bulb. Oil and/or other contaminants from
hands can leave residue on the bulb causing premature bulb
failure. It is advisable to wear soft cotton gloves.
CAUTION:
• To Replace the Silver Ion Probe, see page 16.
• To reinstall the cover, see page 17.
Do not operate LaundryPure
with the UV shield or front
cover removed or improperly
installed. Failure to follow
these instructions can result
in severe eye damage,
death, or electrical shock.
DANGER:
