R E M O V I N G U V B U L B S
Remove Cover (see page 13) then
remove the UV shield by loosening the
six (6) thumb nuts on the top and
bottom edges.
Pull the UV shield forward and away
from the unit. The UV shield is
attached to the unit with a tether. DO
NOT REMOVE, CUT, OR ALTER THE
TETHER OR THE UV SHIELD.
Locate the UV bulbs. The LaundryPure unit
ships with zip tie straps to hold the UV bulbs
in place during shipment. Cut with a pair of
scissors or diagonal cutters to remove.
These do not need to be replaced.
After removing the ties, pull the right end of
the bulb toward you to remove from clip.
Remove the electrical socket by pulling
the bulb through its retainer grommet
while holding onto the socket. The bulb
will unplug.
After removing, dispose of UV bulbs in
accordance with local ordinances.
2
1
3
4
5
SOCKET RETAINER GROMMET
Electrical Shock Hazard.
Disconnect power before attempting
service. Failure to follow these instructions
can result in death, fire, or electrical shock.
WARNING:
For optimal performance, UV
bulbs (item #US70963) should be
replaced immediately if
nonfunctional, or every three
years.
TETHER
Do not operate LaundryPure with the UV shield or front cover
removed or improperly installed. Failure to follow these instructions
can result in severe eye damage, death, or electrical shock.
DANGER:
ZIP TIES
