INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
1. ACRONYMS AND ABBREVIATIONS
2. PRODUCT DESCRIPTION
CIP — Clean-in-place PCB — Printed circuit board
FF — Forward ush P&ID — Piping and instrumentaon diagram
NC — Normally closed RO — Reverse osmosis
NO — Normally open BW — Brackish water
TDS — Total dissolved solids
2.1. OVERVIEW
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilies, or lack of experience and knowledge, unless
they have been given supervision or instrucon concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do
not play with the appliance.
Ecoso RO systems operate as follows.
Raw water is fed through sediment prelter in order to remove parcles. If raw water is treated
with anscalant or other RO chemicals, the prelter housing ensures beer mixing.
Then, high pressure pump feeds the water into the membrane module or membrane array, in
which feed water undergoes separaon process and splits into permeate and concentrate streams.
Permeate (puried water) goes to the permeate outlet and is collected in water tank. Permeate
line is also ed with a pressure switch to halt the unit if signicant pressure builds in permeate
line indicang a full pressurized tank or pipeline shuto.
Float switch has to be put inside an ambient pressure tank (if used) to start and stop the unit
depending on the level of permeate in the tank.
Part of the concentrate stream is discharged to drain via drain rotameter. The rest goes back to
the sucon end of the high pressure pump via recycle rotameter.
Flow rates of drained and recycled concentrate have to be regulated to specied ranges in the
Technical specicaons with the regulang valves built in the rotameters.
When service is interrupted by oat switch or pressure switch signal, the system runs a forward
ush (membrane rinse) cycle, then switches to standby. The controller receives temperature and
conducvity of permeate, permeate level, pressure switch statuses, and external inhibion signals.
Ecoso brackish water reverse osmosis systems are used for demineralizing water in industrial,
municipal, commercial applicaons. Ecoso BW RO system can be used to demineralize low to
medium salinity feed water. System components comprise stainless steel skid, prelter housing,
high pressure pump, pressure vessels with membranes, electrical panel, process controller, and the
necessary valves and instruments.
