3. Operating and Programming
3.2 Quick Start
Charging Dock Placement
Connect the Power Adapter to the Charging Dock.
Place the Charging Dock on a level oor surface
against the wall with the base perpendicular to
the ground. Keep the immediate area 1.5m (5’) in
front of the charger and 0.5m (1.6’) on both sides
of the charger clear of objects and reective
surfaces.
Plug the Charging Dock in.
1
Install Side Brushes
Attach Side Brushes to the bottom of DM85 by
pressing a brush into each slot with the matching
color until it clicks.
3
Install Battery
Insert the Battery Pack into the battery slot
on the bottom of DM85. Insert and tighten the
screws with a coin to secure the Battery Pack.
22
