2. Package Contents and Technical Specifications
2.3 Product Diagram
Robot
Charging Dock
1
2
3
1. Infrared Signal Generator
2. Charging Dock Pins
3. Power Adapter with Plug
1. Top Cover
2. Control Panel
3. Anti-Collision Sensors
4. Anti-Drop Sensors
5. Charging Contacts
6. Side Brushes
7. Main Brush Option
8. Driving Wheels
9. Universal Wheel
10. Battery Pack with Screws
11. Smart Clean Reservoir Slots
12. Infrared Receiver for Remote Control
13. Dust Sensors
14. Upgrade Port (Contact Customer Service
before trying to upgrade the robot)
15. Dust Bin
1. Spot Cleaning Mode Button
2. Edge Cleaning Mode Button
3. AUTO Mode Button
4. Intensive Cleaning Mode Button
5. Return to Charger Mode Button
Control Panel
1
2
3
4
5
6
7
8
13 1415
1 3 5
2 4
9
10
11
12
