Figure 5: Wind speed cup installation diagram
5.3.4 Install Batteries in sensor package
Open the battery compartment with a screwdriver and insert 2 AA
batteries in the battery compartment. The LED indicator on the back of
the sensor package (item 9) will turn on for four seconds and then flash
once every 16 seconds indicating sensor data transmission. If you did not
pay attention, you may have missed the initial indication. You can always
remove the batteries and start over, but if you see the flash once every 16
seconds, everything should be OK.
Figure 6: Battery installation diagram
Note: If LED does not light up or is on permanently, make sure the
battery is inserted the correct way and inserted fully, starting over
if necessary. Do not install the batteries backwards as it may
permanently damage the outdoor sensor.
