Introducing the Motherboard

Table of Motherboard Components

LABEL COMPONENTS

1. CPU Socket

Socket for AMD Phenom

II processor (socket AM3)

2. CPU_FAN

CPU cooling fan connector

3. DDR3_1~4

240-pin DDR3 SDRAM slots

4. ATX_POWE

Standard 24-

in ATX

ower connecto

5. IDE

Primar

IDE connecto

6. SATA1~6

Serial ATA connectors

7. SYS_FAN

System cooling fan connector

8. F_PANEL

Front Panel switch/LED header

9. PWR_BTN

Power on button

10. RST_BTN

Reset button

11. SPI_DEBUG

SPI DEBUG header

12. CLR_CMOS_BTN

Clear CMOS button

13. F_USB1~3

Front Panel USB headers

14. F_1394A

Onboard 1394a header

15. SPDIFO

SPDIF out header

16. F_AUDIO

Front Panel Audio header

17. PCI

32-bit add-on card slot

18. PCIE1~2

PCI Express x1 slots

19. PCIEX16

PCI Express x16 slot for graphics interface

20. PWR_FAN

Power cooling fan connector

21. ATX12

8-pin +12V power connecto

This concludes Chapter 1. The next chapter explains how to install the motherboard.

Questions and Answers:

Need help?

Do you have a question about the ECS A785GM-M and is the answer not in the manual?

ECS A785GM-M Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	6
Controller interface type	AMD SB710
PS/2 ports quantity	0
eSATA ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC888S
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
RAID levels	0, 1
LAN controller	RealTek RTL8111D(L)
