PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
Shutdown Temperature (CPU) Disabled
Shutdown Temperature (NB)
85°C/185°F
CPU Temperature : 40°C/104°F
NB Temperature : 56°C/132°F
System Temperature : 33°C/91°F
CPU Fan Speed : 2606 RPM
PWR Fan Speed : N/A
System FAN Speed : N/A
CPU Vcore : 1.344 V
Vcc NB : 1.088 V
Vcc SB : 1.200 V
VDIMM : 1.600 V
VBAT : 2.928 V
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
f
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
SMART FAN Control (Enabled)
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
This item allows you to enable/disable the control of the system fan speed by chang-
ing the fan voltage.
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quite mode, the fan
speed will be auto minimized for quiet environment. If you choose Silent mode, the
fan speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
Smart Fan Mode Normal
SMART Fan start PWM value. 28
SMART Fan start TEMP. (°C) 27
DeltaT1 +3
SMART Fan Slope PWM value 3 PWM value/°C
CPU FAN Full Limit Temp. 60°C
PWR Fan Control Disabled
System Fan Control Disabled
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F1:General Help
: Move
mnlk
Options
F9: Optimized Defaults
Options
Normal
Quiet
Silent
Manual
