ECS A785GM-M User Manual

34
Using BIOS
Advanced Chipset Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Advanced Chipset Setup
Internal Graphics Mode UMA
GFX Clock Override Disabled
Share Memory Size Auto
Init Display First PCI
HDMI Audio Enabled
DCT Unganged Mode Always
Help Item
Disabled
UMA
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
HDMI Audio (Enabled)
This item is used to enable or disable the onboard audio chip.
DCT Unganged Mode (Always)
This item is used to select the DCT mode (DRAM Controller mode).
Internal Graphics Mode (UMA)
Use this item to choose the onboard VGA mode. You can select [Disabled] to disablethe
onboard VGA, [UMA] to use the system memory.
Warning: If Disabled Internal Graphics Mode, please Load-
ing default toEnable it.
GFX Clock Override (Disabled)
Use this item to enable or disable GFX Clock Override.
Share Memory Size (Auto)
This item lets you allocate a portion of the main memory for the onboard VGA
display application.
Init Display First (PCI)
Use this item to select which graphics controller to use as the primary boot devices.
Options

ECS A785GM-M Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	6
Controller interface type	AMD SB710
PS/2 ports quantity	0
eSATA ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC888S
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
RAID levels	0, 1
LAN controller	RealTek RTL8111D(L)
