ECS A785GM-M User Manual

41
Using BIOS
M.I.B. II (MB Intelligent Bios)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
M.I.B. II(MB Intelligent BIOS)
Help Item
AMD Athlon (tm) II X2 250 Processor
Speed : 3000MHz, NB CLK: 2000MHz
Current CPU Frequency 3000MHz
Current CPU Voltage 1.3250v
Current NB Frequency 2000MHz
DIMM Voltage Default 1.60v
NB Voltage Default 1.15v
SB Voltage Default 1.20v
Memory Configuration Press Enter
HT Frequency Auto
CPU/HT Reference Clock (MHz) 200
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
CPU Voltage Disabled
DIMM Voltage Disabled
NB Voltage +50mV
SB Voltage 1.20 v
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
mnlk
f
Memory Configuration
f
Scroll to this item and press <Enter> to view the following screen:
Help Item
Memory CLK : 533MHz, N/A
CAS Latency (Tcl) : 8CLK, N/A
RAS/CAS Delay (Trcd) : 8CLK, N/A
Row Precharge Time (Trp) : 8CLK, N/A
Min Active RAS (Tras) : 20CLK, N/A
RAS/RAS Delay (Trrd) : 4CLK, N/A
Row Cycle (Trc) : 27CLK, N/A
Memory Configuration
DRAM Frequency Auto
DRAM Timing Mode Auto
Bank Interleaving Auto
Channel Interleaving XOR of Address bits
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
mnlk
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Memory Configuration
Auto
Limit
Manual
Options

ECS A785GM-M Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	6
Controller interface type	AMD SB710
PS/2 ports quantity	0
eSATA ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC888S
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
RAID levels	0, 1
LAN controller	RealTek RTL8111D(L)
