Introducing the Motherboard

Chapter 1

Introducing the Motherboard

Introduction

Currently, the memory maximum size we have tested is 16 GB.

Thank you for choosing the A785GM-M motherboard. This motherboard is a high

performance, enhanced function motherboard that supports socket for AMD

Phenom

II processor (socket AM3) for high-end business or personal desktop

markets.

The motherboard incorporates the AMD 785G Northbridge (NB) and SB710

Southbridge (SB) chipsets. The Northbridge supports the HyperTransport

3.0 in-

terface. The memory controller supports DDR3 memory DIMM frequencies of

1333/1066. It supports four DDR3 slots with maximum memory size of 32 GB

. One

PCI Express x16 slot, intended for Graphics Interface, are fully compliant to the PCI

Express Gen2 (version 2.0). In addition, two PCI Express x1 slots are supported.

The SB710 Southbridge supports one PCI slot which is PCI v2.3 compliant. It

integrates USB 2.0 interface, supporting up to twelve functional ports (six USB ports

and three USB 2.0 headers support additional six USB ports). One onboard IDE

connector supports two IDE devices in Ultra ATA 133/100/66/33 modes. The

Southbridge integrates a Serial ATA host controller, supporting six SATA ports with

maximum transfer rate up to 3.0 Gb/s each. It provides AMD SATA RAID configura-

tion with RAID 0, 1 and 10 modes supported.

There is an advanced full set of I/O ports in the rear panel, including one DVI port,

one VGA port, one HDMI port, one 1394A port, two eSATA ports, six USB ports,

one optical SPDIFO port, one LAN port and audio jacks for microphone, line-in and

8-ch line-out.

Questions and Answers:

Need help?

Do you have a question about the ECS A785GM-M and is the answer not in the manual?

ECS A785GM-M Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	6
Controller interface type	AMD SB710
PS/2 ports quantity	0
eSATA ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC888S
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
RAID levels	0, 1
LAN controller	RealTek RTL8111D(L)
