Installing the Motherboard

F_USB1~3: Front Panel USB headers

The motherboard has six USB ports installed on the rear edge I/O port array. Addi-

tionally, some computer cases have USB ports at the front of the case. If you have

this kind of case, use auxiliary USB connector to connect the front-mounted ports to

the motherboard.

Please make sure that the USB cable has the same pin assignment as

indicated above. A different pin assignment may cause damage or system

hang-up.

1 USBPWR Front Panel USB Power

2 USBPWR Front Panel USB Power

3 USB_FP_P0- USB Port 0 Negative Signal

4 USB_FP_P1- USB Port 1 Negative Signal

5 USB_FP_P0+ USB Port 0 Positive Signal

6 USB_FP_P1+ USB Port 1 Positive Signal

7 GND Ground

8 GND Ground

9 Key No pin

10 USB_FP_OC0 Overcurrent signal

Function

Pin Signal Name

Questions and Answers:

Need help?

Do you have a question about the ECS A785GM-M and is the answer not in the manual?

ECS A785GM-M Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	6
Controller interface type	AMD SB710
PS/2 ports quantity	0
eSATA ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC888S
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
RAID levels	0, 1
LAN controller	RealTek RTL8111D(L)
