30
Using BIOS
For the purpose of better product maintenance, the manufacture reserves
the right to change the BIOS items presented in this manual. The BIOS
setup screens shown in this chapter are for reference only and may differ
from the actual BIOS. Please visit the manufacture’s website for updated
manual.
Standard CMOS Setup
This option displays basic information about your system.
Date Wed 06/24/2009
f
IDE Master Not Detected
IDE Slave Not Detected
SATA1 Not Detected
SATA 2 Not Detected
SATA 3 Not Detected
SATA 4 Not Detected
SATA5 Not Detected
SATA6 Not Detected
Help Item
f
CMOS Setup Utility -- Copyright (C) 1985-2005, American Megatrends, Inc.
Time 02:52:22
User [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
Standard CMOS Setup
Date & Time
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the Windows Date and Time Properties utility.
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
IDE BusMaster Enabled
f
f
f
IDE Master
f
This motherboard supports six SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
CMOS SETUP UTILITY – Copyright (C) 1985-2005, American Megatrends, Inc.
IDE Master
IDE Master
Type Auto
LBA/Large Mode
Block (Multi-Sector Transfer Auto
PIO Mode Auto
DMA Mode Auto
S.M.A.R.T Auto
32Bit Data Transfer Enabled
Help Item
Select the type
of device connected
to the system.
Device : Not Detected
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
Auto
f
f
f
